4.3 Selection tables
SIVACON 8PS - Configuring with LX system
Configuration Manual, 10/2011, A5E02194899-02
33
4.3.1.2 Straight trunking units with tap-off points
Standard length with up to 5 tap-off points top and bottom selectable
Length L
[m]
Position of the
tap-off point
ADO-U
[m]
Type
1)
Type suffix tap-
off point
0.67 +LX-A
1.17 +LX-B
1.67 +LX-C
2.17 +LX-D
/
$'28
$'28
$'28
$'28
$'28
3.0
2.67
LX.....-3-ADO-
U
+LX-E
1)
See type code 1
Standard length with up to 5 tap-off points selectable, on one side
Length L
[m]
Position of the
tap-off point
ADO-U
[m]
Type
1)
Type suffix tap-
off point
0.67 +LX-F
1.17 +LX-G
1.67 +LX-H
2.17 +LX-I
/
$'
$'
$'
$'
$'
3.0
2.67
LX.....-3-AD
+LX-K
