Dimension drawings
8.1 Straight trunking units
SIVACON 8PS - Configuring with LX system
160 Configuration Manual, 10/2011, A5E02194899-02
8.1.2 Straight trunking units without tap-off points
3(11
/
/
/
,
169B

,

D
169B
Figure 8-3 LXA(C)01 to 07
,

D
169B
Figure 8-4 LXA(C)08 to 10
System l a
LXA(C)01, LXA(C)02 137
LXC03, LXA(C)04 162
LXA(C)05 207
LXA(C)06, LXA(C)07 287
LXA(C)08 439
LXA(C)09, LXA10
350...3000
599
