Siemens SIVACON 8PS User Manual

Dimension drawings
8.2 Junction units
SIVACON 8PS - Configuring with LX system
Configuration Manual, 10/2011, A5E02194899-02
163
Knee (here: LX... - LH)
169B

D
\
[
///3(11
Figure 8-9 LXA(C)01 to 07
169B

D
\
[
///3(11
Figure 8-10 LXA(C)08 to 10
System x y a
LXA(C)01, LXA(C)02 137
LXC03, LXA(C)04
350...700 (1100) 350...700 (1100)
162
LXA(C)05 207
LXA(C)06, LXA(C)07
500...850 (1200) 500...850 (1200)
287
LXA(C)08 439
LXA(C)09, LXA10
800...1150 (1500) 800...1150 (1500)
599
