Product description
3.1 Overview of Siemens busbar trunking systems
SIVACON 8PS - Configuring with LX system
16 Configuration Manual, 10/2011, A5E02194899-02
Up to 5000 A
LD system
The busbar trunking system for optimum power distribution in industry:
● Reliable and safe operation
● Quick and easy installation
● Space-saving compact design up to 5000 A in one enclosure
● Tap-off points for loads up to 1250 A
● IP34 degree of protection with air cooling (IP54 with sealed enclosure)
● Type-tested connection to distribution boards and transformers
For further information: See also the planning manual Planning with SIVACON 8PS. Busbar
trunking systems up to 6300 A (order number: A5E01541101)
Up to 6300 A
LX system
The busbar trunking system for power transmission and distribution in buildings
● Reliable and safe operation
● Quick and easy installation
● Sandwich design up to 5000 A (6300 A on request)
● Tap-off points for loads up to 1250 A
● High degree of protection IP54 or IP55 for use in harsh industrial environments
● Type-tested connection to distribution boards and transformers
LR system
The busbar trunking system for power transmission under extreme ambient conditions (IP68)
● Reliable and safe operation
● Quick and easy installation
● Cast resin system up to 6150 A
● Type-tested connection to distribution boards and transformers
● High degree of protection IP68 for outdoor applications
For further information: See also the planning manual Planning with SIVACON 8PS. Busbar
trunking systems up to 6300 A (order number: A5E01541101)
SIMARIS design dimensioning software
SIMARIS design makes dimensioning electrical power distribution systems easy, fast and
safe.
To download a free demo version of SIMARIS design and to find out more, please visit:
SIMARIS design (http://www.siemens.com/simarisdesign
)
