Configuration
6.1 Basic knowledge for configuring
SIVACON 8PS - Configuring with LX system
92 Configuration Manual, 10/2011, A5E02194899-02
● Standard version with sheet-steel flange plate and cable sleeves
● With single-core cables, it is necessary to order an undrilled aluminium plate +LX-BPAL
● Connection options via all the trunking units and junction units listed in the catalogue.
Figure 6-5 Cable feeder units
Note
Scope of delivery
M12 bolts for cable connection are included in the scope of supply.
Cable clamps for supporting the cable to be inserted by the customer.
No standard types are available for the following systems:
LX...30
LX...52
LX...53
LX...54
LX...61
LX...62
Please contact Product Support if required.
