Configuration
6.1 Basic knowledge for configuring
SIVACON 8PS - Configuring with LX system
Configuration Manual, 10/2011, A5E02194899-02
97
Type (code) of the connection systems for SIVACON S4 and S8
Size
1)
Busbar system
Connection system
2)
…….-FA8PQ
Aluminium version
LXA01 41(51) LXC03 41(51)
LXA02 41(51) LXA05 41(51)
LXA04 41(51) LXA05 41(51)
LXA05 41(51) LXA05 41(51)
LXA06 41(51) LXA06 41(51)
LXA07 41(51) LXA07 41(51)
LXA08 41(51) LXA08 41(51)
LXA09 41(51) LXA09 41(51)
LXA10 41(51) LXA10 41(51)
Copper version
LXC01 41(51) LXC03 41(51)
LXC02 41(51) LXC07 41(51)
LXC03 41(51) LXC03 41(51)
LXC04 41(51) LXC07 41(51)
LXC05 41(51) LXC06 41(51)
LXC06 41(51) LXC06 41(51)
LXC07 41(51) LXC07 41(51)
LXC08 41(51) LXC08 41(51)
LXC09 41(51) LXC09 41(51)
①
Connection systems for LX systems with conductor configurations with the key
digits 30, 52, 53, 54, 61 and 62 are only available on request.
②
Dimensions of the connection systems are only available on request.
