310
Spine
Hint
• You could repeat the same protocol by simply click-
ing the chronicle with the right mouse button for
repeat.
Emotion 6 L3-4 L4-5 L5-S1
kV 130 130 130
Effective mAs/
Quality ref.
mAs
280 280 320
Rotation time 1.5 sec. 1.5 sec. 1.5 sec.
Acquisition 6 x
1.0 mm
6 x
1.0 mm
6 x
1.0 mm
Slice
collimation
1.0 mm 1.0 mm 1.0 mm
Slice width 2.0 mm 2.0 mm 2.0 mm
Feed/Scan 6.0 mm 6.0 mm 6.0 mm
Kernel B31s B31s B31s
CTDI
Vol
35.56
mGy
35.56
mGy
40.64
mGy
Effective dose
Male:
Female:
0.88 mSv
1 . 4 4 m S v
0.91 mSv
1.96 mSv
0.81 mSv
3 . 5 2 m S v

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
