Specials
459
Additional Important Information
Independently from the Interventional Window but-
tons on the Interventional Toolbar you can use for
faster windowing the function keys F2, F3 and F4 are
implemented with standard window settings for Abdo-
men, Lung and Bone. Modifying them is possible
under Options> Configuration> Examination> Win-
dowing.
If you repeat a CARE Vision or Biopsy scan range the
window setting last used will be applied to your new
images. Inserting the next scan range by using the
Patient Model Dialog will reset this function so that
the default window setting will be applied.
If you want to change the window values you can do
this under Option> Configuration> Viewing> Evalu-
ation General but be aware you do not change it for
the Interventional values only but for all window set-
tings. If you don’t want to change it for all window val-
ues you can for example change it for the Abdomen to
350/50 and save this as a new window setting with a
new name, then you can apply these values as your
interventional window settings and have the General
window settings set as before.

Table of Contents

Other manuals for Siemens SOMATOM

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens SOMATOM and is the answer not in the manual?

Siemens SOMATOM Specifications

General IconGeneral
CategoryCT Scanner
Rotation Time0.25 seconds
Tube Voltage70-150 kV
Bore Size78 cm
Max Table Load250 kg
Gantry Aperture78 cm
Table Weight Capacity250 kg
X-ray Tube Voltage70-150 kV
Scan Time per Rotation0.25 seconds
SoftwareSyngo
ConnectivityDICOM
