Siemens SOMATOM Manual&Nbsp;

Specials
441
CAREVisionSingle
The images will be reconstructed and displayed with
one time 10 mm slice thickness and a kernel of B30.
Emotion 16 CAREVision
kV 130
Effective mAs/
Quality ref. mAs
30
Rotation time 0.6 sec.
Acquisition 2 x 5.0 mm
Slice collimation 5.0 mm
Slice width 10.0 mm
Feed/Scan 0.0
Increment 1.0 mm
Kernel B31s
CTDI
vol
3.06 mGy
Emotion 6 CAREVision
kV 130
Effective mAs/
Quality ref. mAs
30
Rotation time 0.6 sec.
Acquisition 2 x 5.0 mm
Slice collimation 5.0 mm
Slice width 10.0 mm
Feed/Scan 0.0
Increment 1.0 mm
Kernel B31s
CTDI
vol
2.85 mGy

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
