Siemens SOMATOM Manual&Nbsp;

426
Specials
PolyTrauma/
PolyTrauma06s
Two combined ranges are predefined, head with neck
and thorax with abdomen.
For SOMATOM Emotion 16-slice configuration:
A scan range of 12/14 cm will be done in 13.36/9.68
sec.
Emotion 16 Head Neck
kV 130 130
Effective mAs/
Quality ref. mAs
240 150
Rotation time 1.0 sec. 1.0 sec
Acquisition 16 x 1.2 mm 16 x 1.2 mm
Slice collimation 1.2 mm 1.2 mm
Slice width 6.0 mm 5.0 mm
Feed/Rotation 10.6 mm 19.2 mm
Pitch Factor 0.55 1.00
Increment 6.0 mm 5.0 mm
Kernel H31s B50s
CTDI
Vol
57.60 mGy 16.80 mGy
Effective dose
Male:
Female:
2.63 mSv
2.88 mSv
3.08 mSv
3.37 mSv

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
