Siemens SOMATOM Manual&Nbsp;

Specials
427
Take a new Topogram for the thorax and abdomen
range.
A scan range of 20/40 cm will be done in 9.01/
9.53 sec.
Emotion 16 Thorax AbdPelvis
kV 130 130
Effective mAs/
Quality ref. mAs
50 90
Rotation time 0.6 sec. 0.6 sec
Acquisition 16 x 1.2 mm 16 x 1.2 mm
Slice collimation 1.2 mm 1.2 mm
Slice width 8.0 mm 8.0 mm
Feed/Rotation 15.4 mm 28.8 mm
Pitch Factor 0.80 1.50
Increment 8.0 mm 8.0 mm
Kernel B41s B41s
CTDI
Vol
5.60 mGy 10.08 mGy
Effective dose
Male:
Female:
1.94 mSv
2.53 mSv
8.47 mSv
10.60 mSv

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
