Siemens SOMATOM

Pelvis
329
Hint
• In case of 3D study only, images should be recon-
structed with at least 50% overlapping and kernel
B10.
• If only one side is examined, it is advisable to enter
the side in the comment line on the routine card.
Emotion 6 Hip 2
nd
reconstr.
kV 130
Effective mAs/
Quality ref. mAs
100
Rotation time 1.0 sec.
Acquisition 6 x 1.0 mm
Slice collimation 1.0 mm
Slice width 5.0 mm 5.0 mm
Feed/Rotation 9.0 mm
Pitch Factor 1.50
Increment 5.0 mm 5.0 mm
Kernel B70s B60s
CTDI
Vol
12.70 mGy
Effective Dose Male: 3.60 mSv
Female: 3.16 mSv
