Siemens SOMATOM Manual&Nbsp;

356
Lower Extremities
* Adjust the mAs value to the body region.
Hint
• For image reconstruction of soft tissue, use kernel
B30s/B31s.
Emotion 6 ExtrHR 2
nd
reconstr.
kV 130
Effective mAs/
Quality ref. mAs*
60
Rotation time 1.0 sec.
Acquisition 6 x 0.5 mm
Slice collimation 0.5 mm
Slice width 2.0 mm 1.0 mm
Feed/Rotation 2.6 mm
Pitch Factor 0.85
Increment 2.0 mm 0.6 mm
Kernel U90s U90s
CTDI
Vol
7.68 mGy
Effective dose Male: 0.01 mSv
Female: 0.01 mSv

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
