Vascular
381
Emotion 16 ThorAngio 2
nd
reconstr.
kV 110
Effective mAs/
Quality ref. mAs
70
Rotation time 0.6 sec.
Acquisition 16 x 0.6 mm
Slice collimation 0.6 mm
Slice width 5.0 mm 1.0 mm
Feed/Rotation 14.4mm
Pitch Factor 1.50
Increment 5.0 mm 0.7 mm
Kernel B31s B20s
CTDI
Vol
5.60 mGy
Effective dose Male: 2.92 mSv
Female: 3.78 mSv
Emotion 6 ThorAngio 2
nd
reconstr.
kV 110
Effective mAs/
Quality ref. mAs
70
Rotation time 0.8/0.6 sec.
Acquisition 6 x 1.0 mm
Slice collimation 1.0 mm
Slice width 5.0 mm 1.25 mm
Feed/Rotation 9.0mm
Pitch Factor 1.50
Increment 5.0 mm 0.8 mm
Kernel B31s B20s
CTDI
Vol
5.81 mGy
Effective dose Male: 2.96 mSv
Female: 3.83 mSv

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
