Siemens SOMATOM Manual&Nbsp;

Vascular
389
Emotion 16 ThorAngioECG 2
nd
reconstr.
kV 130
Effective mAs/
Quality ref. mAs
280
Rotation Time 0.5 sec.
Acquisition 16 x 1.2 mm
Slice collimation 1.2 mm
Slice width 3.0 mm 1.5 mm
Feed/Rotation 7.3 mm
Pitch Factor 0.38
Increment 3.0 mm 0.8 mm
Kernel B31s B31s
Temp. resolution
*
*. depends on heart rate
up to 125 ms
CTDI
Vol
31.36 mGy
Effective dose Male: 13.88 mSv
Female: 18.66 mSv

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
