Respiratory Gating
493
The timebase of the respiratory curve is realtime in an
updating mode.
Images can be reconstructed at any user defined Inha-
lation- or Exhalation level.
Example:
– 20% Ex: Patient has exhaled to 80%
– 20% In: Patient has inhaled to 20 %
Inhalation Phase
100% Inspiration
Exhalation Phase
0% Expiration
