Siemens SOMATOM Manual&Nbsp;

Children
519
* The conversion factor for a 7-year-old child, and a
scan range of 120 mm was used.
Emotion 16 Head
kV 110
Effective mAs/
Quality ref. mAs
230
Rotation time 1.5 sec.
Acquisition 16 x 1.2 mm
Slice collimation 1.2 mm
Slice width 4.0 mm
Feed/Rotation 10.6 mm
Pitch Factor 0.55
Increment 4.0 mm
Kernel C30s
CTDI
Vol
36.80 mGy
Effective dose Male: 2.83 mSv*
Female: 2.89 mSv*
Emotion 6 Head
kV 110
Effective mAs/
Quality ref. mAs
230
Rotation time 1.5 sec.
Acquisition 6 x 1.0 mm
Slice collimation 1.0 mm
Slice width 5.0 mm
Feed/Rotation 2.4 mm
Pitch Factor 0.40
Increment 5.0 mm
Kernel C30s
CTDI
Vol
42.32 mGy
Effective dose Male: 1.70 mSv*
Female: 1.69mSv*

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
