Siemens SOMATOM Manual&Nbsp;

548
Children
* The conversion factor for a 7-year-old child, and a
scan range of 150 mm was used.
Emotion 6 ThorRoutine 2
nd
reconstr.
kV 110
Effective mAs/
Quality ref. mAs
26
Rotation time 0.8/0.6 sec.
Acquisition 6 x 2.0 mm
Slice collimation 2.0 mm
Slice width 5.0 mm 5.0 mm
Feed/Rotation 18.0 mm
Pitch Factor 1.50
Increment 5.0 mm 5.0 mm
Kernel B41s B60s
CTDI
Vol 1.85 mGy
Effective dose Male: 1.69 mSv*
Female: 1.98 mSv*

Siemens SOMATOM Specifications

General

Category	CT Scanner
Rotation Time	0.25 seconds
Tube Voltage	70-150 kV
Bore Size	78 cm
Max Table Load	250 kg
Gantry Aperture	78 cm
Table Weight Capacity	250 kg
X-ray Tube Voltage	70-150 kV
Scan Time per Rotation	0.25 seconds
Software	Syngo
Connectivity	DICOM
