SDM3045X Digital Multimeter 13
To Measure DC Voltage
The Multimeter enables to measure DC Voltage up to 1000V. The method to
connect and measure DC Voltage will be introduced in details as the following
steps.
Operating Steps:
1. Press on the front panel to enter the DC Voltage measurement
interface, as shown in Diagram 2- 4.
Diagram 2- 4 DC Voltage Measurement Interface
2. Connect the red lead to terminal Input-HI and black lead to terminal
Input-LO as the following diagram.
Diagram 2- 5 Sketch Map for Measuring DC Voltage
