SDM3045X Digital Multimeter 41
Dual-display Function
Dual-display function is used to improve test and measurement functions.
Press to open Dual-display function and the upper right corner will
show “Dual”. By this time, press a function key if this function can be used as
the vice display, it will be displayed in the Vice Display. The Main Display will
display the function that is selected before the Dual-display function is turned
on. All the available combinations are listed in table 2-12.
Table 2- 12 Available Main/Vice Function Combinations (shade is available)
Main Display Function
DCV
DCI
ACV
ACI
FREQ
PERIOD
2WR
4WR
Cap
Vice
Display
Function
DCV
DCI
ACV
ACI
FREQ
PERIOD
2WR
4WR
Cap
Explanations:
1. If the same measurement function is used in both Main and Vice Display.
 The readings in both of the display will update at the same time.
 If math function (dBm, dB) is used in Main Display, when opening Vice
Display, math operation will be closed automatically and Vice Display will
show the same measurement result as Main Display.
 If math function (Statistics, Limits, Relative) is used in Main Display, when
opening Vice Display, the result will still be shown in Main Display and
Vice Display will show the same measurement result as Main Display.
2. If different measurement functions are used in both Main and Vice Display.
 The readings in both of the display will update alternately.
 If math function (dBm, dB) is used in Main Display, when opening Vice
Display, math operation will be closed automatically and Vice Display will
