SIGLENT
SDM3045X Digital Multimeter 15
To Measure DC Current
The Multimeter enables to measure DC Current up to 10A. The method to
connect and measure DC Current will be introduced in details as the following
steps.
Operating Steps:
1. Press and on the front panel to enter the DC Current
measurement interface, as shown in Diagram 2- 6.
Diagram 2- 6 DC Voltage Measurement Interface
2. Connect the red lead to terminal Input-I and black lead to terminal
Input-LO as the following diagram.
Diagram 2- 7 Sketch Map for Measuring DC Current
