60 SDM3045X Digital Multimeter
Help System
SDM3045X provides powerful built-in help system. You can recall help
information at any time during using the instrument. You also can get a
particularly help for every button on the front panel or menu softkey by using
the built-in help system. Or you can get help about familiar operations with
the help list.
Press and to enter the help list, as the following diagram
shows.
Diagram 2- 55 Help Menu
Table 2- 20 Help System Operating Menu
Function
Menu
Description
Up
Move up the cursor and select the help menu.
Down
Move down the cursor and select the help menu.
Select
Select the help information you want and read it.
Done
Return to the higher menu.
1. Basic Measure.
Get basic measurement types and methods to connect the leads in different
measurements.
2. Measuring Temperature.
Get the method to measure temperature.
