SIGLENT
SDM3045X Digital Multimeter 25
To Measure Capacitance
The Multimeter enables to measure Capacitance up to 1000μF. The method to
connect and measure Capacitance will be introduced in details as the following
steps.
Operating Steps:
1. Press on the front panel to enter the Capacitance measurement
interface, as shown in Diagram 2- 16.
Diagram 2- 17 Capacitance Measurement Interface
2. Connect the red lead to terminal Input-HI and black lead to terminal
Input-LO as the following diagram.
Diagram 2- 18 Sketch Map for Measuring Capacitance
