24 SDM3045X Digital Multimeter
3. Choose a proper resistance range according to the scope.
Table 2- 6 Measurement Characteristics of 4-Wire Resistance
Ranges*
200Ω、2kΩ、20kΩ、200kΩ、2MΩ、10MΩ、100MΩ
Open-circuit Voltage
<8V
Input Protection
(1) 1000V on each range (HI terminal)
(2) 200V on each range (HI Sense, LO Sense)
Configurable Parameters
Range, Speed, Rel
NOTE*:
All the ranges enable to obtain 20% value higher than original. Besides, both
Manual and Auto are available for setting every range.
4. Set relative value (Optional operation).
Press 【Rel】 to open or close Relative math function. When it is opened, the
reading displayed is a value which comes from the result of actual
measurement value subtracts the relative value that has been set. The default
relative value is the measurement value when the function is opened.
(Please refer to “ Math Functions” in Chapter 2 to know about the details.)
5. Read measurement result.
Select required measurement rate (reading rate) by pressing 【Speed】
and read the measurement result.
6. View history data.
There are four types of way to view historical data: “Number”, “Bar
Meter” ”Trend Chart” and “Histogram”.
NOTE：
Please do not put the terminals of the resistance on the conductive plane or
in your hand to avoid error. The bigger of the resistance, the more affection it
will be brought.
