32 SDM3045X Digital Multimeter
The default value is set as 50Ω before leaving factory. The value can be
changed by using direction keys. You also can execute the Continuity
measurement directly without modification.
Table 2- 10 Measurement Characteristics of Continuity
Test Current
1mA
Ranges*
Fixed at 2kΩ
Open-circuit Voltage
<8V
Input Protection
1000V on all ranges (HI terminal)
Beep Condition
0≤R
testing
≤Short-circuit impedance
0Ω≤Short-circuit impedance≤2kΩ
4. Set the Beeper function.
Press 【Beeper】to turn on or off the Beeper. If the circuit is continuous, the
instrument will beep continually when the Beeper is turned on.
5. Search for the test point and read measurement result.
NOTE:
Before testing continuity, please cut off the power and discharge all the
high-voltage containers to avoid damages to the Multimeter.
