SDM3045X Digital Multimeter 47
The method of inputting file name:
 Press direction keys to select a desired char in the input area.
 Press “OK” key on the front panel to input selected char in the input area.
 Press【Clear All】to clear all input chars.
 Press【Delete Char】to delete the letter on which the cursor taking place.
 Press【Previous Char】to move the cursor in the file name area to the
previous char.
 Press【Next Char】to move the cursor in the file name area to the next char.
 Press【Done】to save the current file and return to the higher level menu.
 Press【Cancel】to cancel the current operation and return to the higher
level menu.
4. Press【Action】and select【Folder】, 【Capture Display】, 【Copy】,
【Rename】or【Delete】to do the corresponding operation.
Table 2- 15 Action Settings
Function
Menu
Description
Folder
Press【Create Folder】to create a new folder.
Capture
Display
Press【Save Screen】to save current captured screen picture
as standard BMP format.
Copy
Press【Perform Copy】to copy the selected file.
Rename
Press【Perform Rename】to rename the selected file.
Delete
Press【Perform Delete】to delete the selected file.
Done
Save all changes and return to the higher level menu.
