SDM3045X Digital Multimeter 75
Histogram
Operating Steps:
1. Press【Histogram】to enter Histogram display mode.
Diagram 2- 68 Histogram Display Mode
Table 2- 29 Histogram Display Mode
Function
Menu
Settings
Description
Display
Histogram
Currently selected display mode is Histogram.
Binning
Set Binning as Auto or Manual mode.
Bin Set
Set the parameters of Bin.
Cumulative
On/Off
Turn on or off Cumulative function.
Clear
Readings
Clear all current readings and restart statistics.
2. Press【Binning】to choose the way to set Binning as Auto or Manual mode.
When in Manual mode, press【Bin Settings】to enter the following interface.
Diagram 2- 69 Bin Set Interface
