Sigma Digital SLR Camera SD14 User Manual

105
LIST OF MENU FUNCTIONS
Menu Item Options Description Page
Set Custom WB…
[Dialog] Captures the image to be used for
the custom white balance setting.
56,57
Adjust Setting
Contrast
Sharpness
Saturation
Color Space
Sets image parameter and color
space.
59~60
Date/Time… [Dialog] Sets the date and time in the
camera’s internal clock and the
format in which the date and time
will be displayed.
27
Language/言語
English *
日本語
Deutsch
中 文
Français
Español
Italiano
한국어
Sets the language in which menus
and messages will be displayed.
26
Quick Preview Off
2 sec.*
5 sec.
10 sec.
Hold
Sets the duration of the Quick
Preview image that is automatically
displayed on the color LCD monitor
after the image is captured.
72,73
Preview Style Image only *
Info screen
Sets the type of information
displayed in the Quick Preview
image.
74
Folder Manager Create Folder
Folder Select
Creates a new folder and enables
the selection of folders for image
recording.
32,33
Exp. Warning
Off *
On
Sets whether or not the over -
exposure warning is shown on
images.
84
OK Shortcut None *
Lock/Unlock
Mark/Unmark
Rotate
,
Rotate
Exp. warning
Sets the function that the
＜ OK ＞
button will perform during image
review.
98,99

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
