Sigma Digital SLR Camera SD14 User Manual

77
VIEWING ONE IMAGE AT A TIME
Press button on the back of the camera to
see recorded images in Single-Image View.
While in Single-Image View:
• Press arrow on the 4-way controller to
see next image.
• Press
arrow on the 4-way controller to
see previous image.
• Press
arrow on the 4-way controller to
change the indicated information. It is
possible to select the information bar from
the following three patterns.
File numbering, Aperture, Shutter speed, ISO sensitivity
File numbering, year/month/date, hour/minute/second
File numbering, Folder name, Recording quality, Resolution mode, file number / total files recorded
TIP
• It is not necessary to wait for the current image to finish loading before
proceeding to another image.
• To scroll through images more quickly, press and hold a button on the 4-way
controller. Images will advance automatically until the button is released.
• The first and last recorded images on the CF card are linked. Pressing the
arrow on the 4-way controller while the first image is displayed brings up the
last recorded image on the card. Pressing the arrow on the 4-way
controller while the last image is displayed brings up the first recorded image
on the card.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
