Sigma Digital SLR Camera SD14 User Manual

115
AUTO POWER OFF
In order to conserve battery power, the SD14 camera goes into a low-power
mode if not used for a predetermined amount of time. The Auto Power Off
timeout can be set using the Camera Set-up Menu to 10 seconds, 30 seconds, 1
minute, 5 minutes, or Off. The default setting is 30 seconds.
TIP
• The VIEW and MENU buttons will not be active when the camera is in
low-power mode. This prevents the color LCD monitor from being
accidentally turned on and draining the battery while the camera is not being
used. To reactivate the VIEW and MENU buttons, simply press the shutter
halfway or turn the "D"-dial to another position and back; this will take the
camera out of low-power mode and allow you to perform all regular camera
functions.
• It will still be possible to take pictures while the camera is in low-power
mode. To take a picture simply press the shutter button half-way to activate
the exposure metering and autofocus mechanism, then press the shutter
fully to take the picture.
• The Auto Power Off timeout counter will not start until the color LCD monitor
is turned off, either manually or by the LCD Sleep timeout.
AUTO POWER OFF OPTIONS
OPTION DESCRIPTION
10 seconds Camera goes into low-power mode if not used for 10 seconds.
30 seconds
Camera goes into low-power mode if not used for 30 seconds.
1 minute
(Default)
Camera goes into low-power mode if not used for 1 minute.
5 minutes
Camera goes into low-power mode if not used for 5 minutes.
Off The Auto Power Off function is disabled.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
