Sigma Digital SLR Camera SD14 User Manual

31
FILE NUMBERING SYSTEM
The images you take are automatically assigned file numbers from 0001 to 9999.
When images are being reviewed, the file number of each image is displayed in
the left corner of the Info Strip (see
P. 7 7 ). The file number is also incorporated
into the filename of the image. The filename consists of “SDIM” followed by the
4-digit file number and extension. For example: image number 0023 will be
stored in the file SDIM0023.X3F. All SD14 image files will be stored in the /
###SIGMA folder on the CF card.
File numbering can be continuous, or can be reset every time an empty card is
detected. Use the Camera Set-up Menu to set the file numbering system.
FILE NUMBERING OPTIONS
OPTION DESCRIPTION
Continuous
(Default)
Numbering is continuous. The first file number assigned on an
empty card will be one higher than the last assigned number. (If
the inserted card contains SD14 images with file numbers
greater than the last assigned number, file numbering will
continue with one higher than the highest file number on the
card.)
Auto Reset Each time an empty CF card is inserted, or all images on the
current card are deleted, the file number will reset to its default
value of 0001. (If the inserted card already contains SD14
images, the file number will not be reset).
TO SET FILE NUMBERING SYSTEM
1
Make sure the camera is turned on.
2
Press the button on the back of the
camera to display the Camera Set-up Menu.
(See P.104)
3
Use arrows on the 4-way controller to
select “File Numbering”.
4
Press arrow or to open the sub-menu.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
