Sigma Digital SLR Camera SD14 User Manual

52
CONTINUOUS SHOOTING
In this mode, when you keep the shutter button fully depressed, the camera will
take pictures continuously. At the time of continuous shooting the number of
frames per sec. is given below.
The maximum number of frames and speed of continuous shooting are as follows:
RES (Recording mode)
Super Hi HI MED LOW
61224
RAW
3.0 3.0 3.0
6 6 12 24
FINE
3.0 3.0 3.0 3.0
6 6 12 24
NORM
3.0 3.0 3.0 3.0
6 6 12 24
QUAL
(Recording quality)
BASIC
3.0 3.0 3.0 3.0
The upper rows show the maximum number of frames, the lower rows show the
maximum shooting speed in continuous mode (frames per second).
CAUTION !!
• When AF mode is set to AF (Single AF mode) mode and the focus
indicator in the viewfinder is on, focus distance and exposure value are fixed
at the setting for the first picture. It is possible that focus and exposure could
be incorrect, if subject moves or the brightness changes. When AF mode is
set to AF mode (Continuous AF mode), then camera will focus on the
subject continuously. However, depending on the subject situation, since the
shutter release has the first priority there is a possibility that the picture may
be out of focus.
• When you use the continuous shooting mode with external flash, the camera
may be slow, because the camera will not take pictures, while the flash is
re-charging.
• Images taken in rapid succession, such as during Continuous shooting, are
initially stored in the camera's internal memory buffer. This allows you to
continue shooting without having to wait for images to be recorded to the CF
card. Once the memory buffer is full, the shutter will be disabled until some
images have been transferred to the CF card.
SELF TIMER
When you want to include yourself in the picture or avoid camera shake, please
use the self-timer.
When you set the self-timer to 10s, then the shutter will be released 10seconds
after you fully press the shutter button.
When you set the self-timer to 2s, then the shutter will be released 2seconds
after you fully press the shutter button.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
