Sigma Digital SLR Camera SD14 User Manual

27
SETTING THE TIME AND DATE
The SD14 camera records the date and time when each image is captured and
stores this information with the image. To ensure that the correct information is
recorded with each image, set the camera’s internal clock to the correct date and
time before using the camera for the first time or after extended periods of
disuse.
1
Make sure the camera is turned on.
2
Press the button on the back of the
camera to display the Camera Set-up Menu.
(See P.104)
3
Use the arrows on the 4-way controller to
select “Date/Time…”.
4
Press the arrow or the to open the
date/time set-up page.
5
Use the arrows on the 4-way controller to
select a setting and use the
arrows to
cycle through the setting options.
6
Once all changes have been made, press
to save the settings and return to the main
menu.
•Press
at any time to close the date/time
set-up page without saving any of the changes.
TIP
• The date can be displayed in one of three formats: mm/dd/yyyy (month/day/year),
dd/mm/yyyy (day/month/year), or yyyy/mm/dd (year/month/day).
• The camera’s internal clock is powered by a capacitor that receives its charge from
camera’s battery. If the camera is without battery for an extended period of time,
such as after prolonged storage, the internal clock will need to be reset.
• You can synchronize the date and time on the SD14 camera to your computer by
using the “Set Date and Time…” option in the Camera menu of the SIGMA Photo
Pro software (See SIGMA Photo Pro Manual provided on the CD-ROM).

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
