Sigma Digital SLR Camera SD14 User Manual

43
USING THE BUILT-IN FLASH
The cameras have built-in flash for taking pictures at night or in low light,
which is very convenient.
USING THE BUILT-IN FLASH
P mode, use this mode for automatic
photography. The flash sync speed and
aperture are set automatically. If the subject is
too dark, the flash indicator ”
” in viewfinder
will blink, then you can take a flash exposure
by following.
1
Grasp the built-in flash (see picture) and lift it
up gently.
2
Wait for the mark to appear in the
viewfinder.
■When you lift up the built-in flash, it will start charging. While the built-in flash is
charging, the
mark is not visible, but when the flash is sufficiently charged,
the indicator in viewfinder and on the LCD panel, will show
mark.
■During the charging, the shutter cannot be released.
■After you finish using the built-in flash, close the flash head by pressing the top
part of the flash down.
■When you use the built-in flash continuously, the grip of the camera will
become warm. This is normal and not a defect.
CAUTION !!
• The lens hood may intrude into the light path of the built-in flash unit,
resulting in a shadow at the bottom of the picture. (The same phenomenon is
possible with a lens, which has a large front lens and long length) Either
remove the lens hood, or use an external Sigma dedicated flash.
• To prevent overheating and protect the built-in flash unit after using
continous shooting with flash, please do not use your flash for a while,.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
