Sigma Digital SLR Camera SD14 User Manual

103
CHANGING SLIDESHOW SETTINGS
You can customize slideshows by setting the length of time that images will be
displayed and specifying whether or not the slideshow will repeat itself
continuously.
SETTING OPTIONS DESCRIPTION
Duration
2 sec (default),
5 sec, 10 sec,
Manual
Set the length of time that each image in a
slideshow is displayed. (When set to “Manual”,
each image will remain on the screen until the
slideshow is manually advanced.)
Repeat
Yes (default),
No
Set whether the slideshow loops continuously or
stops on the last image.
TO CHANGE SLIDESHOW SETTINGS
1
Press to display the Modification Menu.
2
Use the arrows on the 4-way controller to
select the Slideshow Menu.
3
Use the arrows on the 4-way controller to
select “Settings…”.
4
Press to open the slideshow set-up page.
5
Use the arrows on the 4-way controller to
select a setting and use the
arrows to cycle through the setting options.
6
Once all changes have been made, press
to save the settings and return to the
Slideshow Menu.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
