Sigma Digital SLR Camera SD14 User Manual

108
REFERENCE
OPTIONAL ACCESSORIES
REMOTE CONTROLLER RS-31
Wireless remote control, permits releasing the shutter from a place away from the
camera. Time for a shutter release can be set up in two stages. Moreover, a setup of
a channel is also possible, to avoid interference with other cameras and remote
controls. （For detailed information please refer page 67）
POWER GRIP PG-21
This battery pack extends power capacity of the SD14 two times and can also be
used as a vertical position grip. Two BP-21 Lithium-ion batteries can be used in
Power Pack SD. In addition, it is equipped with a vertical shutter release to hold the
camera steady in the vertical position.
ELECTRONIC FLASH EF-500 DG SUPER SA-STTL
Auto zoom flash with abundant light and STTL Automatic Exposure with the
maximum guide number 50/m (165/ft) (ISO100).
EF-500 DG SUPER SA allows you to use many advanced flash techniques such as
“STTL system Auto Flash” or Multi Flash etc. (Please refer to page 70 for details).
ELECTRONIC FLASH EF-500 DG ST SA-STTL
Auto zoom flash with abundant light and STTL Automatic Exposure with the
maximum guide number 50/m (165/ft) (ISO100). It provides a proper flash exposure
under any lighting conditions and it is equipped with bounce flash function, same as
EF-500 DG Super. (Please refer to page 70 for details.)
CABLE RELEASE SWITCH CR-21
It can connect with release socket, on the camera body, and the shutter can be
released, without touching the camera. This accessory minimizes the camera shake,
which can result in blurriness of your photograph, especially when using Mirror up
and a super-telephoto lens. （It is connected to release socket of the camera. Since
it is not equipped with “Halfway” operation. Please press the shutter button
“Half-way” and check the exposure. Please adjust the focus manually.）
AC ADAPTER SAC-2
This is used to provide a constant electricity supply when shooting in the studio, or
taking indoor shots. It is also recommended for use when connecting the camera
to your computer to transfer data.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
