Sigma Digital SLR Camera SD14 User Manual

1
Thank you for purchasing
the Sigma Digital Autofocus Camera
The Sigma SD14 Digital SLR camera is a technical breakthrough! It is powered by
the Foveon® X3™ image sensor, the world’s first image sensor to capture red,
green and blue light at each and every pixel. A high-resolution digital single-lens
reflex camera, the SD14 delivers superior-quality digital images by combining
Sigma’s extensive interchangeable lens line-up with the revolutionary Foveon X3
image sensor. You will get the greatest performance and enjoyment from your new
SD14 camera’s features by reading this instruction manual carefully before
operating it. Enjoy your new Sigma camera!
SPECIAL FEATURES OF THE SD14
■ Powered by Foveon X3 technology.
■ In addition to RAW format data recording system, this camera also incorporates easy to
use and high quality JPEG recording format. Super high quality JPEG format recording
mode makes the best use of the characteristic of FOVEON
®
X3
TM
image sensor.
■ Dust protector keeps dust from entering the camera and adhering to the image sensor.
■ Mirror-up mechanism and depth-of-field preview button support advanced
photography techniques.
• Please keep this instruction booklet handy for future reference. Doing so will allow
you to understand and take advantage of the camera’s unique features at any time.
• The warranty of this product is one year from the date of purchase. Warranty terms
and warranty card are on a separate sheet, attached. Please refer to these materials
for details.
Disposal of Electric and Electronic Equipment in Private Households
Disposal of used Electrical & Electronic Equipment (Applicable in the European Union
and other European countries with separate collection systems)
This symbol indicates that this product shall not be treated as household waste.
Instead it shall be collected separately for the recycling of electrical and electronic
equipment.
If the new products are purchased, this product might be handed over to the distributor
or the collection system of waste electrical and electronic equipment eventually.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product or components of this product.
If this product is disposed illegally, it might cause a possibility of penalties.
For more detailed information about recycling of this product, please contact your local
city office, your household waste disposal service or the shop where you have
purchased the product.

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
