66
■ For the first frame, “
” mark will be displayed continuously on the LCD
panel. For the second frame, “
” mark on the LCD panel, will blink slowly,
then it will blink quickly for the third frame.
■ When you set the self-timer mode, the camera will automatically take three
consecutive pictures.
■ It is possible to change the drive mode during the Auto Bracketing operation.
But if you set the self-timer mode, the camera will take three continuous
pictures.
■ It is not possible to use Auto Bracketing mode for flash photography. Auto
Bracketing will not affect the output level of the flash.
Auto Bracketing mode can be used in combination with Exposure
Compensation.
You can take pictures with Auto Bracketing mode based on a compensated
exposure, which you set.
To do so, please set both the Auto Bracketing mode and Exposure Compensation
mode as desired.
The combined value (Exposure Compensation and Auto Bracketing) will be
indicated on the viewfinder display.
Example
Exposure Compensation +1.7 with Auto Bracketing amount 1.0
First Frame
1.7 (Exposure compensation +1.7 & no shift value)
Second Frame
0.7 (Exposure compensation +1.7 & shift value -1.0)
Third Frame
2.7 (Exposure compensation +1.7 & shift value +1.0)

Sigma Digital SLR Camera SD14 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18（ISO100）
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	8-segment Evaluative Metering, Center Metering, Center-Weighted Average Metering
Metering Range	EV 1 to 20（with 50mm F1.4 at ISO100）
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO 100, 200, 400, 800, (1600)
Exposure Compensation	±3EV（in 1/3steps）
AE Lock	Push button type
Auto Bracketing	±3EV （ in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure）
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Shutter Speeds	1/4000sec to 30sec, Bulb up to 30sec Flash Synchronization at 1/180sec.
Storage Media	CompactFlash™ (CF) (TypeⅠ/Ⅱ), HITACHI MicroDrive™
Aspect Ratio	3：2
Resolution	Super Hi(JPEG) : 4608 x 3072, HI：2640 x 1760 MED：1776 x 1184, LOW：1296 x 864
Interfaces	USB 2.0, Video Out (NTSC／PAL)
