Simplex 4010 Service Manual

2-1
Trouble messages are the primary means by which the system indicates that a
problem has occurred.
This chapter organizes trouble messages by major system components. For
example, the section on IDNet troubles contains trouble messages related to
IDNet points, as well as trouble messages for the IDNet channel itself.
This chapter discusses the following topics:
Topic See Page #
NAC Troubles 2-2
Power Supply Troubles 2-4
IDNet Troubles 2-8
RS-232/Modem Troubles 2-11
SDACT Troubles 2-12
Network Troubles 2-13
24 Point I/O Troubles 2-14
LCD Troubles 2-15
4009 IDNet NAC Extender Troubles 2-16
Digital Pseudo Point Troubles 2-17
Chapter 2
Interpreting Trouble Messages
Introduction
In this Chapter
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
