1-4
Meter AC Power
@ Panel's AC
Terminal Block.
AC Power Less
than 103 VAC?
NO
Contact Individual / Organization
Responsible for Building Electrical
System
Brownout Adjustment
Potentiometer Correctly
Positioned? Refer to
Appendix B.
NO
Adjust Brownout Potentiometer.
Note:
Read Appendix B for
Adjustment Procedure.
YES
Meter DC Power
@ Terminals H1 and H2
DC Power 21-32 VDC?
YES
NO
Check and Replace (if necessary)
Transformer and Bridge Rectifier.
Refer to Appendix B.
AC Power Flowchart
Technical Manuals Online! - http://www.tech-man.com
To Next Page
