B-1
This appendix provides basic troubleshooting procedures related to the 4010
FACP’s power supply.
This appendix discusses the following topics:
Topic See Page #
Adjusting the AC Power Supply Brownout
Potentiometer
B-2
Checking AC Power Supply Transformer / Bridge
Rectifier
B-3
Checking EPS Transformer / Bridge Rectifier B-6
Appendix B
Power Supply
Adjustment and Troubleshooting
Introduction
In this Appendix
