C-5
Network diagnostics allow you to check the node number of the 4010, the
network topology, and network attendance.
Figure C-2 shows a typical Network Topology screen. Topology information
shows how the network is physically wired and whether there are any breaks in
the network loop.
Figure C-2. Network Topology Screen
Attendance information shows if the network nodes are configured. Each
position on the 4010’s LCD represents a node’s address for a maximum of 80
nodes (only 80 nodes can be displayed because there are only 80 positions on
the 2 by 40 character LCD). Each node can only be represented by one
character. Figure C-3 is NOT a typical Attendance screen, it is shown for
reference only.
Figure C-3. Network Attendance Screen
Network Diagnostics
Network Diagnostics
M2 4 (1) L5 ❚
❚❚
❚ 67R9
1M.4L❚
❚❚
❚7.R0...........2..................
..3...................................9.
1 = Node Number 1
M = Monitor Node (Node Number 2)
. = No node configured at this address
4 = Node Number 4
L = Node Number 5 (fifth position on the
screen) and it is the Left End Node.
❚
❚❚
❚ = Missing Node
7 = Node Number 7
R = Node Number 9 (ninth position on the
screen and it is the Right End Node.
2 = Node Number 22 (twenty-second position
on the screen)
3 = Node Number 43 (forty-third position on the
screen)
9 = Node Number 79 (seventy-ninth position on
the screen)
M = Monitor Node
L = LEFT End Node
R = RIGHT End Node
(_) = This Node
❚
❚❚
❚ = Missing Node
