Keep the following in mind when reviewing this table:
• 4010 Phase 1 features are compatible with any mix of SFIO card, SFIO
firmware, BIN file, and programmer software (BIN and programmer
software must be same revision level).
• The Rev. C SFIO board provides improved overload protection for the U9
voltage regulator.
• QuickAlert functionality for the 4010 SFIO’s NACs requires the Rev. C
SFIO board, Version 2 SFIO firmware, and Version 2 of the BIN file and
programmer application.
• Discrete battery trouble reporting requires the Rev. C SFIO board,
Version 2 SFIO firmware, and Version 2 of the BIN file and programmer
application.
• 4009 IDNet NAC Extenders require the Rev. B or Rev. C SFIO board,
Version 2 SFIO firmware, and Version 2 of the BIN file and programmer
application.
• All other 4010 Version 2 features are supported by either version of the
SFIO card and SFIO firmware, but you must have Version 2 of the BIN
file and programmer application.
Feature
SFIO Board
Rev. B
565-736
SFIO Board
Rev. C
(565-736)
SFIO FW
Version 1
742-147
SFIO FW
Version 2
742-147
Programmer
and BIN File
Version 1
741-108 &
107
Programmer
and BIN File
Version 2
741-108 &
107
Phase 1
Features
Yes Yes Yes Yes Yes Yes
IDNet U9
Overload
Protection
Yes
4010 SFIO
QuickAlert
NACs
Yes Yes Yes
FM Battery
Charger TBL
Yes Yes Yes
4009 IDNet
Interface
Yes Yes Yes Yes
Other Version 2
Features
Yes Yes Yes Yes Yes
Continued on next page
Determining Compatibility between Versions 1 and 2
Introduction
Table A-1. Compatibility Matrix for Versions 1 and 2
