Simplex 4010 Service Manual

A-3
Using the programmer to edit jobs on a panel containing older versions of the
SFIO chip and board has the following effect:
• After saving the job, the panel tags the job as a Phase II job.
• Subsequent editing of the job cannot take advantage of the full set of Phase
II features, despite the job’s Phase II designation.
Because this situation may become confusing, it is recommended that you
upgrade the panel’s SFIO card and SFIO firmware before editing its job with the
Phase II programmer.
Determining Compatibility between Versions 1 and 2, Continued
Using the Version 2.x
Programmer with Version 1.x
Jobs
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
