Simplex 4010 Service Manual

The 4010 is listed for the following.
UL 864 Listings for Type of System:
• UL 864 Power-Limited Fire Alarm Control Unit
• Local (formerly NFPA 72A)
Requires the sounding of an alarm via listed notification appliance(s)
• Auxiliary (formerly NFPA 72B)
Requires 4010-9809 City Circuit Module
• Remote Station - protected premise (formerly NFPA 72C)
Requires 4010-9809 City Circuit Module or the 4010-9810 or -9816 DACT
• Proprietary - protected premise (formerly NFPA 72D)
Requires 4010-9817 (with 4010-9818 or 4010-9819) or 4010-9821 Network
Interface Modules
• Central Station - protected premise (formerly NFPA 71)
Requires 4010-9810 or -9816 DACT
• Suppression Releasing Service
Requires 4010-9814 Suppression Kit
UL 864 Listings for Type of Service:
• Automatic, Manual, Waterflow, and Sprinkler Supervisory
UL 864 Listings for Type of Signaling:
• Coded, Non-Coded, March-Time and DACT
DACT requires the 4010-9810 or -9816
Factory Mutual Approved
• Same as UL above
Local Approvals
• CSFM
• MEA
Continued on next page
Codes and Standards
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
