4100U-S1 Programming Guide Document: LT0400
Adding Addressable Devices
Page 5-4 15 December 2010 Issue 1.4
Enter Custom Label into the Custom
Label box
The Custom Label is limited to
40 characters. It is recommended that the first
characters be the point address, followed by the
description of the point location and then lastly
the zone number.
e.g. M1-188 FOYER RECEPTION DESK ZN01
To continue entering new devices click
the APPLY or NEXT buttons.
5.2 Assigning Devices to Zones
Once addressable devices have been entered into the configuration (refer Section 5.1) they can then
be assigned to Zones on the 4100U. This is done by adding the device to preset Lists as follows:
Select the LIST tab
