13 Engine Removal & Installation
Kohler - Engine Installation
Figure 15. Drive Shaft Guard/Shield Installation
A. Guard Mounting Hardware C. Shield Mounting Hardware
B. Drive Shaft Guard D. Drive Shaft Shield
D
A
C
B
Figure 16. PTO Component Installation
A. PTO Belt Set B. Fan C. PTO Clutch Assembly
A
C
B
