13 - 27
13 Engine Removal & Installation
Kawasaki - Engine Installation
Figure 31. Engine Component Installation – Right
A. Negative Battery Cable D. Fuel Line G. Right Ignition Coil J. Right Shield
B. Positive Battery Cable E. Heat Shield H. Upper Shield Hardware
C. Negative Battery Cable F. Muffler I. Upper Shield
F
C
G
J
E
D
I
H
B
A
