Simplicity LEGACY Series User Manual

7 Electrical System Service
Diesel Engine Models
7 - 10
30
Note: 30
Amp fuse (Ref. No. 17)
used with early models only
,
later models use a 30 Amp
circuit breaker (Ref. No. 8).
1
To Alternator
To "G" Terminal
of Alternator
To Tachometer
Sender
To Rear Wire
Harness
To Starter
To Engine
Sump Bolt
To Engine
Mount (Frame)
To Glow
Plug Relay
To Preheat Timer
To Glow Plugs
To Engine
Temperature
Sender
To Fuel Filter
To Rear
PTO Switch
(Optional)
To Engine
Mount (Frame)
To PTO
Clutch
To Oil Pressure
Sender
To Fuel Solenoid
To Starter
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1718
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
7
16
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
Figure 4. Exploded View Diagram – Upper Wiring Harness (Diesel Engine Models)
Not for Reproduction

Simplicity LEGACY Series Specifications

General

Engine Brand	Briggs & Stratton
Transmission	Hydrostatic
Deck Type	Fabricated
Cruise Control	Yes
Cutting Width	52 in.
Turning Radius	18 inches
Cutting Height	1.5 - 4.5 in.
Deck Material	Steel
Warranty	3 years
