7 Electrical System Service
Diesel Engine Models
Upper Wiring Harness (Diesel Engine Models)
REF NO. QTY. DESCRIPTION
1 2 JUMPER
2 1 SWITCH, Headlights
3 8 BULB, Instrument Panel
4 1 INSTRUMENT PANEL, Diesel
5 1 WIRE HARNESS, Main
6 1 HARNESS, Power Outlet
7 4 FASTENER, Panel
8 1 CIRCUIT BREAKER, 30 Amp (Later Models Only)
9 4 NUT, Hex Flange
10 1 SWITCH, Mower Height Adjust
11 1 SWITCH & KEY ASSEMBLY (Includes Ref 12 thru 15)
12 1 KEYS (Set of 2)
13 1 COVER, Key Switch
14 1 NUT, Hex Flange
15 1 WASHER, Internal Tooth
16 1 COVER, Terminal
17 1 FUSE, 30 Amp, Automotive (Early Models Only)
18 1 SWITCH, Front PTO
19 1 BREAKER, Circuit
20 2 CAPSCREW
21 1 SWITCH, Interlock (NO/NO)
22 2 NUT, Hex Lock
23 1 HARNESS, Headlight
24 1 CLIP
25 2 BULB, Headlight, Halogen
26 1 BEZEL, Headlight
27 1 LOCKWASHER
28 1 NUT, Hex Jam
29 1 COVER, Starter Terminal
30 1 COVER, Positive Battery Terminal
31 1 CABLE, Battery to Starter
32 1 GUARD, Battery
33 1 BATTERY
34 2 ROD, Battery Hold-Down
35 1 BRACKET, Battery
36 2 WASHER, Plain
37 2 NUT, Hex, Nylon Lock
38 1 CABLE, Battery to Ground
39 7 TIE
